Product Name | plastic crate mould |
Mould Cavity | Single Cavity |
Mould Steel | S50C/P20H/718/H13/2738/S136 etc. |
Steel Hardness | 28-50HRC |
Mould Base | LKM,DME,HASCO,self-made etc. |
Mould Runner | Hot/Cold |
Gate | Point Gate, Side Gate, direct gate way,Sub-Gate,Tab Gate, Fan Gate |
Ejection | Stripper Plate, Ejection Block, Ejectors Pins,gas,Cylinder |
Mould Life | 》1,000,000 Shots ,Different steel with different mold life |
Production Time | 30-50days ,it depend on product |
Mould Parts | China standard / SKD |
Mould Quality Levels | Level A quality(Highest Level Quality),Level B quality(Middle Level Quality),Level C quality(Lowest Level Quality) , different
level with different price |
Attention
| When you send us the mould inquiry, please offer the following information:
1) Quality level you choose: Level A/Level B/Level C
2) Photo together with dimension/ drawing design |
Mould Quality Control
| For the Q/C of mould, there are 3 steps:
1.Mould Material Q/C
- Mould Steel Checking,Standard Spare Parts Checking
2. Mould Making Process Q/C
- Design checking ,Each part of mould's size checking after machining according to 2D drawing , Mould testing
3.Check with customer's requirement again before mould shipping. |
